MAD Design Group / EcoSmart Fire

Pod 40 Fire Pit w/ Gas/LP Burner

In stock — ready to ship

$3,695.00
Application Outdoor
Application Outdoor

Gas burners can ONLY be used outdoors.

Color Natural
Color

Burner Finish Stainless Steel

Fire Screen (Optional for Concrete Models)
-- Please Select --

ESF.5.A.G.R530

EcoSmart Fire R530 Fire Screen

EcoSmart Fire R530 Fire Screen

The round-burner screen. Four panels around a Pod, an Ark or a Martini, low enough that it does not turn the fire into an exhibit and tall enough to do the job.

Key features

A flame that stands still
Moving air is what makes an outdoor flame wander, gutter and burn through a fill faster than it should. Four panels of glass around it and the fire behaves the way it does indoors.
Glass chosen for how it fails
Ultra-low-iron toughened glass, specified to break into small blunt pieces rather than shards. On a table people lean over, that is the property that matters most.
Nothing to fix, nothing to store
It sits over the opening under its own weight. Lift it off when you want the fire open, put it back when the wind gets up.

Specifications

Dimensions20.9 x 20.9 x 7.5 in
Weight10.5 lb
MaterialToughened ultra-low-iron glass
UseIndoor or outdoor
FitsPod 30, Pod 40, Ark 40, Martini 50

Fits four of our fire features, in both burner types:

Downloads

Download Spec Sheet
Glass Cover Plate
-- Please Select --

ESF.5.A.CP.R20

EcoSmart Fire R20 Glass Cover Plate

EcoSmart Fire R20 Glass Cover Plate

For the round burners. Six pounds of smoke grey glass that turns a Pod, an Ark or a Martini into an ordinary, useful table for the months you are not lighting it.

Key features

Two pieces of furniture
A fire table earns its space for a few hours an evening. Drop the plate over the burner opening and the other twenty hours are a flat, continuous surface you can put a glass down on.
Smoke grey, not clear
The tint hides the burner tray underneath instead of framing it, so the covered table reads as one surface rather than as a fire table with a lid on.
Toughened throughout
The same grade of glass as our fire screens, rated for the same indoor and outdoor use, with no coating to wear off.
Weatherproof it properly
The plate covers the opening; it does not seal it. Fit the AB8 Burner Cover underneath first and the burner stays dry through a winter as well as a rain shower.

Specifications

Dimensions30.4 x 15.5 x 4.6 in
Weight6 lb
MaterialSmoke grey toughened glass
UseIndoor or outdoor
FitsPod 30, Pod 40, Ark 40, Martini 50

On the ethanol versions of these tables, the cover that goes under it:

Downloads

Download Spec Sheet
Tank Concrete Stools
-- Please Select --

ESF.2.A.TAN.NA

EcoSmart Fire Tank Concrete Stool - Natural

EcoSmart Fire Tank Concrete Stool - Natural

The pale cast. Natural is the finish that reads as stone rather than as concrete, and it is the one that sits quietly next to a Natural surround instead of matching it exactly.

Key features

A stool that hides a bottle
It is hollow. On a gas/LP fire table the propane bottle goes inside it and the tank stops being the thing you arrange the seating around.
Or just a stool
On an ethanol table there is no bottle to hide, and it is still forty-four pounds of cast concrete at seating height - somewhere to sit, or to put a tray down.
Cast, not moulded on
Fluid concrete through the whole section, in the same finishes as the tables, so a stool and a surround bought together age at the same rate.
Heavy on purpose
Forty-four pounds does not move in wind and does not walk across a deck when someone stands up from it.

Specifications

Dimensions17.7 x 17.7 x 20.9 in
Weight44.1 lb
MaterialFluid concrete
UseIndoor or outdoor
FinishNatural

Downloads

Download Spec Sheet

ESF.2.A.TAN.GH

EcoSmart Fire Tank Concrete Stool - Graphite

EcoSmart Fire Tank Concrete Stool - Graphite

The dark cast. Graphite disappears at dusk, which is when a fire table is doing its work and when you would rather look at the flame than at the furniture around it.

Key features

A stool that hides a bottle
It is hollow. On a gas/LP fire table the propane bottle goes inside it and the tank stops being the thing you arrange the seating around.
Or just a stool
On an ethanol table there is no bottle to hide, and it is still forty-four pounds of cast concrete at seating height - somewhere to sit, or to put a tray down.
Cast, not moulded on
Fluid concrete through the whole section, in the same finishes as the tables, so a stool and a surround bought together age at the same rate.
Heavy on purpose
Forty-four pounds does not move in wind and does not walk across a deck when someone stands up from it.

Specifications

Dimensions17.7 x 17.7 x 20.9 in
Weight44.1 lb
MaterialFluid concrete
UseIndoor or outdoor
FinishGraphite

Downloads

Download Spec Sheet

ESF.2.A.TAN.BO

EcoSmart Fire Tank Concrete Stool - Bone

EcoSmart Fire Tank Concrete Stool - Bone

The warmest of the three. Bone is a shade off white, which holds its own against teak and against a pale stone terrace where Natural can read as grey.

Key features

A stool that hides a bottle
It is hollow. On a gas/LP fire table the propane bottle goes inside it and the tank stops being the thing you arrange the seating around.
Or just a stool
On an ethanol table there is no bottle to hide, and it is still forty-four pounds of cast concrete at seating height - somewhere to sit, or to put a tray down.
Cast, not moulded on
Fluid concrete through the whole section, in the same finishes as the tables, so a stool and a surround bought together age at the same rate.
Heavy on purpose
Forty-four pounds does not move in wind and does not walk across a deck when someone stands up from it.

Specifications

Dimensions17.7 x 17.7 x 20.9 in
Weight44.1 lb
MaterialFluid concrete
UseIndoor or outdoor
FinishBone

Downloads

Download Spec Sheet

Optional add-ons need JavaScript to be added alongside this product. With JavaScript disabled you can still order the item above, then add any accessories from their own pages.

Questions?

Call (936) 939-6195 or email support@avenzaoutdoor.com.
Monday to Friday, 9:00 AM – 5:00 PM CST.

Pod 40 Fire Pit w/ Gas/LP Burner

Inspired by the shapes and forms of traditional pottery, the Pod Fire Bowl Series brings a modern update to the classic fire pit — and the Pod 40 is its fullest expression. Its smokeless fire provides a warm and inviting outdoor centrepiece to gather around and relax in front of, no matter the season.

The generous rim offers real surface for glasses and small plates, and an optional glass cover plate allows for easy conversion to a coffee table when the fireplace is not in use. Hand-cast in Fluid™ Concrete from a blend of green cement and recycled materials, the Pod 40 resists scratches, stains, mould and mildew, and is available in Ethanol, Natural Gas or Liquid Propane.

Round, grounded and quietly monumental, the Pod 40 gives a poolside deck or courtyard a natural centre of gravity.

That the same object can serve indoors or out comes down to EcoSmart's burner technology: plant-based ethanol is certified for interior and exterior installation, while natural gas and liquid propane deliver higher heat in outdoor settings. Neither ethanol nor liquid propane requires a fixed utility connection.

Seating arranges itself in a circle around an open flame — it always has. The Pod 40 makes that arrangement permanent, and gives a garden or terrace a reason to be used every evening rather than a few afternoons a year.

Fire, in the round, with nothing to sweep up afterwards.

Included Accessories

Decorative Glass Charcoal

Decorative Glass Charcoal

Fuel Efficiency

Volume Capacity
N/A — LP or natural gas supply
Heats on Average
Outdoor use only
Minimal Room
Outdoor use only
Thermal Output
65,000 BTU/h · 19 kW
Burn Time
8–20 h (LP) · Unlimited (NG)

Figures are indicative. Actual performance varies with the model purchased, the installation environment, and the composition of the e-NRG bioethanol available in your region.

Specifications

Full Specifications

Full Specifications
Model Pod 40
Type Fire Pit
Fuel Liquid Propane or Natural Gas
Burner LP/NG
Burner Finish Grade 304 Stainless Steel
Surround Material Fluid™ Concrete
Colours Natural, Graphite
Application Outdoor only
Thermal Output 65,000 BTU/h · 19 kW
Fuel Capacity N/A — LP or natural gas supply
Burn Time 8–20 h (LP) · Unlimited (NG)
Heats on Average Outdoor use only
Certification UL/ULC listed to ANSI Z21.97-2017 and CSA 2.41-2017 · Gas Appliance Regulation 2016/426 (CE / UKCA)
Manufacturer MAD Design Group / EcoSmart Fire

Dimensions

Dimensions
Overall Length 39.4 in [1,000 mm]
Overall Width 39.4 in [1,000 mm]
Overall Height 19.8 in [504 mm]
Weight — Complete 110.6 lb [50.3 kg]

Technical Drawings

Pod 40 Fire Pit w/ Gas/LP Burner — Front View technical drawing
Front View
Pod 40 Fire Pit w/ Gas/LP Burner — Top View technical drawing
Top View

Downloads

Read the manual in full before operating the burner. Verify the model's physical dimensions against your cut-out dimensions before installation begins.
